100G QSFP28 BIDI ZR4 "Side B" optical transceiver enables cost-effective 80km single-fiber bidirectional transmission. Its key features include: wavelength inversion (1290nm Tx / 1310nm Rx) for mirrored pairing with Side A modules, strict ZR4 compliance ensuring 80km reach with MSA-standard FEC, mandatory pairing with a "Side A" module for operation, power efficiency < 6W typical consumption, QSFP28 hot-pluggability, and real-time DDM/DCM monitoring for link diagnostics and health.
| Product Features: |
●SFF-8661 Rev 2.5, SFF-8636 Rev 2.10a ●High speed I/O electrical interface (CAUI-4) compliant with IEEE 802.3bm-2015 ●100GBASE-ZR4 103.125G 80km point-to-point Ethernet links ●Rx sensitivity of -28dBm 5E-5 with enabled KR4 FEC in host for up to 80km SMF ●Single 3.3V Supply Voltage ●Power Dissipation 4.5W at 55ºC ,6.5W at 70ºC Case Operating Temperature ●0 ºC is environment temp; 70 ºC is Case Operating Temperature ●LAN WDM EML cooled laser and SOA+PIN cooled Receiver ●Universal QSFP28 MSA package with Simplex LC connector ●Two Wire Serial Interface with Digital Diagnostic Monitoring ●Complies with EU Directive 2011/65/EU (RoHS compliant) ●LPMode, ModPrsL, ModSeIL and ResetL are supported ●Telecom networking ●Class 1 Laser |
●Compliant with QSFP28 Standard: | Applications |
●Data Center Interconnect (DCI): Enables 80km high-bandwidth connections between data centers via single-fiber bidirectional transmission. ●Metropolitan Area Network (MAN) Backbone: Supports 100G high-speed interconnection between urban core nodes with MSA-standard FEC. ●5G Aggregation Layer Backhaul: Connects 5G base stations to core networks with low latency and high reliability. ●Enterprise Campus Interconnection: Facilitates cross-campus data transmission while maintaining compatibility with existing network interfaces. ●Fiber-Optimized Scenarios Reduces deployment costs in fiber-scarce environments through BiDi technology, ideal for legacy network upgrades |
| Data Sheet |
| 100G QSFP28 BIDI ZR4 Side B Transceiver - 80km Single-Fiber MSA Module.pdf |
If you are interested in the 100G QSFP28 BIDI ZR4 Side B Transceiver - 80km Single-Fiber MSA Module,please contact us sales@c-light.com
>
>
>
>
>
>
>
>
